28.920.000 VNĐ
Máy chủ SuperServer SYS-1029P-MT
Máy chủ SuperServer SYS-1029P-MT
- Nhà sản xuất: Supermicro
- Mã sản phẩm/Part No. TM5912 / SYS-1029P-MT
- Tình trạng: Liên hệ đặt hàng
Intel Xeon Scalable Processors Gen 1 &2; 2 x UPI; TDP 70-140W
8 x DIMM slots; Up to 2TB 3DS ECC DDR4-2933MHz
8 x 2.5" Hot-swap
600W- 28.920.000 VNĐ
NVKD sẽ liên hệ lại ngay
Thông tin sản phẩm Máy chủ SuperServer SYS-1029P-MT
Key Features
• Data Center Optimized
• Web Server
• Enterprise Server
• Managed Hosting
• Short Depth
1. Dual Socket P (LGA 3647) support 2nd Gen. Intel® Xeon® Scalable processors (Cascade Lake/Skylake)‡
2. 8 DIMMs; up to 2TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM
3. 1 PCI-E 3.0 x8 (FHHL) slot
4. 8 Hot-swap 2.5" SATA3 drive bays, 1 Slim DVD-ROM drive (optional), Optional PCIe/SATA M.2 drive
5. 2 1GbE LAN ports via Marvell 88E1512
6. IPMI 2.0 + KVM with Dedicated LAN
7. 1 VGA, 2 USB 2.0 (rear)
8. 2 SuperDOM (Disk on Module) ports;1 PCIe/SATA M.2 drive connector
9. 600W High-Efficiency Power Supply Platinum Level Certified
Thông số kỹ thuật Máy chủ SuperServer SYS-1029P-MT
| Server | |
| CPU Sockets | 2 x Socket P (LGA 3647) |
| CPU Support | Intel Xeon Scalable Processors Gen 1 &2; 2 x UPI; TDP 70-140W |
| RAM Support | 8 x DIMM slots; Up to 2TB 3DS ECC DDR4-2933MHz |
| Drive Bays | 8 x 2.5" Hot-swap |
| RAID Controller | Intel C621 |
| RAID Support | RAID 0, 1, 5, 10 |
| Form Factor | 1U |
| PCIe | 1 x PCI-E 3.0 x8 (FHHL) |
| I/O Ports | 2 x USB 2.0; 1 x VGA; 1 x COM port; 2 x SuperDOM |
| Network Interface | 2 x 1GbE LAN, 1 x IPMI LAN |
| Power Supply | 600W |
| Redundant Power | No |
| System Fan | 4 x 4cm 22.5K RPM middle cooling fans |
Cấu hình tùy chọn
CPU
x
Intel Xeon Silver 4110 Processor (8C/16T 11M Cache, 2.10 GHz) - CD8067303561400
10,584,000đ
x
Intel Xeon Platinum 8153 Processor (16C/32T 22M Cache, 2.0 GHz) - CD8067303408900
90,120,000đ
x
Intel Xeon Platinum 8156 Processor (4C/8T 16.5M Cache, 3.6 GHz) - CD8067303368800
199,056,000đ
x
Intel Xeon Platinum 8160 Processor (24C/48T 33M Cache, 2.1 GHz) - CD8067303405600
136,080,000đ
x
Intel Xeon Platinum 8164 Processor (26C/52T 35.75M Cache, 2.0 GHz) - CD8067303408800
173,688,000đ
x
Intel Xeon Platinum 8168 Processor (24C/48T 33M Cache, 2.70 GHz) - CD8067303327701
167,352,000đ
x
Intel Xeon Platinum 8170 Processor (26C/52T 35.75M Cache, 2.10 GHz) - CD8067303327601
210,384,000đ
x
Intel Xeon Gold 6136 Processor (12C/24T 24.75M Cache, 3.0 GHz) - CD8067303405800
60,672,000đ
x
Intel Xeon Gold 6138 Processor (20C/40T 27.5M Cache, 2.0 GHz) - CD8067303406100
74,232,000đ
x
Intel Xeon Gold 6134 Processor (8C/16T 24.75M Cache, 3.2 GHz) - CD8067303330302
62,880,000đ
x
Intel Xeon Gold 6132 Processor (14C/28T 19.25M Cache, 2.6 GHz) - CD8067303592500
50,088,000đ
x
Intel Xeon Gold 5118 Processor (12C/24T 16.5M Cache, 2.30 GHz) - CD8067303536100
27,936,000đ
x
Intel Xeon Gold 5120 Processor (14C/28T 19.25M Cache, 2.20 GHz) - CD8067303535900
35,280,000đ
x
Intel Xeon Gold 6126 Processor (12C/24T 19.25M Cache, 2.60 GHz) - CD8067303405900
51,888,000đ
x
Intel Xeon Gold 6128 Processor (6C/12T 19.25M Cache, 3.40 GHz) - CD8067303592600
48,048,000đ
x
Intel Xeon Gold 6130 Processor (16C/32T 22M Cache, 2.10 GHz) - CD8067303409000
55,344,000đ
x
Intel Xeon Gold 6140 Processor (18C/36T 24.75M Cache, 2.3 GHz) - CD8067303405200
57,840,000đ
RAM
x
Ram Samsung 16GB DDR4-2666 RDIMM
3,960,000đ
x
Ram Samsung 32GB DDR4-2666 RDIMM
4,608,000đ
x
Ram SamSung 64GB DDR4-2666 LRDIMM
9,504,000đ
x
Ram Samsung 16GB DDR4-2666 RDIMM
3,960,000đ
RAID
SSD Samsung PM883 240G SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH240HAHQ
2,257,200đ
SSD Intel DC S3520 960GB M.2 SATA 6Gb/s, SSDSCKJB960G7
12,624,000đ
HDD Seagate 2.5" 600GB SAS 12Gb/s 10K RPM 256MB
3,252,480đ
HDD Seagate 2.5" 600GB SAS 12Gb/s 15K RPM 256MB
4,435,200đ
SSD Samsung PM883 480G SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH480HAHQ
2,864,400đ
SSD Intel S4510 Series 240GB M.2 SATA 6Gb/s 3D TLC (SSDSCKKB240G8)
2,956,800đ
SSD Samsung PM883 960G SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH960HAJR
4,686,000đ
SSD Intel S4510 Series 480GB M.2 SATA 6Gb/s 3D TLC (SSDSCKKB480G8)
3,748,800đ
HDD Seagate 2.5" 1200GB SAS 12Gb/s 10K RPM 256MB
3,991,680đ
SSD Samsung PM883 1.9T SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH1T9HMLT
8,632,800đ
SSD Intel S4510 Series 960GB M.2 SATA 6Gb/s 3D TLC (SSDSCKKB960G8)
6,283,200đ
HDD Seagate 2.5" 2400GB SAS 12Gb/s 10K RPM 256MB
7,392,000đ
HDD Seagate 2.5" 1800GB SAS 12Gb/s 10K RPM 256MB
7,286,400đ
SSD Samsung PM883 3.8T SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH3T8HMLT
16,075,680đ
SSD Intel D1 P4101 256G NVMe PCIe3x4 M.2 22x80mm, 0.5DWPD (SSDPEKKA256G8)
2,956,800đ
SSD Intel S4510 Series 480GB, 2.5in SATA 6Gb/s, 3D2, TLC (SSDSC2KB480G8)
3,168,000đ
SSD Intel D1 P4101 512G NVMe PCIe3x4 M.2 22x80mm, 0.5DWPD (SSDPEKKA512G8)
5,016,000đ
HDD Seagate 2.5" 300GB SAS 12Gb/s 15K RPM 256MB (512N)
4,752,000đ
SSD Intel S4510 Series 960GB, 2.5in SATA 6Gb/s, 3D2, TLC (SSDSC2KB960G8)
5,293,200đ
SSD Intel D1 P4101 1TB NVMe PCIe3x4 M.2 22x80mm, 0.5DWPD (SSDPEKKA010T8)
9,134,400đ
SSD Intel S4510 Series 1.92TB, 2.5in SATA 6Gb/s, 3D2, TLC (SSDSC2KB019T8)
9,543,600đ
SSD Intel D1 P4101 2TB NVMe PCIe3x4 M.2 22x80mm, 0.5DWPD (SSDPEKKA020T8)
17,688,000đ
Network Card
Network card Supermicro AOC-S100G-M2C (2x QSFP28, 100GbE)
28,440,000đ
Network card Supermicro AOC-S40G-I2Q (2x QSFP+, 40GbE)
9,144,000đ
Network card Supermicro AOC-STGN-i2S (2x SFP+, 10GbE)
8,040,000đ
Network card Supermicro AOC-SGP-i4 (4x RJ45, GbE)
4,800,000đ
Network card Supermicro AOC-STGF-I2S (2x SFP+, 10GbE)
7,944,000đ
Network card Supermicro AOC-STGS-I2T (2x RJ45, 10GbE)
7,584,000đ
Network card Supermicro AOC-STG-I4T (4x RJ45, 10GbE)
12,624,000đ
Network card Supermicro AOC-STG-I4S (4x SFP+, 10GbE)
10,344,000đ
Network card Supermicro AOC-STGN-i1S (1x SFP+, 10GbE)
3,480,000đ
Network card Supermicro AOC-STG-I2 (2x CX4, 10GbE)
6,960,000đ
Network card Supermicro AOC-SHFI-I1C (1x QSFP28, 100Gb)
18,312,000đ
Network card Supermicro AOC-STGS-I1T (1x RJ45, 10GbE)
5,856,000đ
Network card Supermicro AOC-S25G-B2S (2x SFP28, 25GbE)
7,824,000đ
Network card Supermicro AOC-STG-B4S (4x SFP+, 10GbE)
10,440,000đ
Network card Supermicro AOC-SGP-i2 (2x RJ45, GbE)
2,616,000đ
Network card Supermicro AOC-STG-i2T (2x RJ45, 10GbE)
8,880,000đ
Network card Supermicro AOC-S25G-I2S (2x SFP28, 25GbE)
9,144,000đ
Riser Card
Riser Card 1U RSC-RR1U-E8
960,000đ
Add-on Card NVMe AOC-SLG3-2E4T
0đ
Heatsink
SNK-P0067PD (1U)
1,200,000đ
Software
Windows Windows Svr Std 2019 64Bit English 1pk DSP OEI DVD 16 Core (P73-07788)
18,792,000đ
Microsoft Windows Server 2019 Device CAL Open Business
816,000đ
Microsoft Windows Server 2019 User CAL Open Business
984,000đ
Microsoft Windows Server Standard 2019 16-Cores Open Business
22,226,400đ
Microsoft Windows Server Standard 2019 2-Cores Open Business
2,904,000đ
