44.880.000 VNĐ
Máy chủ SuperServer SYS-6029P-TRT
Máy chủ SuperServer SYS-6029P-TRT
- Nhà sản xuất: Supermicro
- Mã sản phẩm/Part No. TM5963 / SYS-6029P-TRT
- Tình trạng: Liên hệ đặt hàng
Intel Xeon Scalable Processors Gen 1 & 2; 2 x UPI; TDP 70-205W.
16x DIMM slots; Up to 4TB 3DS ECC DDR4-2933MHz
8x Hot-swap 3.5"
1000W
2x 2.5" NVMe with optional NVMe Drive kit- 44.880.000 VNĐ
NVKD sẽ liên hệ lại ngay
Thông tin sản phẩm Máy chủ SuperServer SYS-6029P-TRT
Key Features
• Cloud and Virtualization needs
• Compute Intensive Application
• Database Processing and Storage
• High Availability Storage
• Hosting & Application Delivery
1. Dual Socket P (LGA 3647) support 2nd Gen. Intel® Xeon® Scalable processors (Cascade Lake/Skylake)‡
2. 16 DIMMs; up to 4TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM, Supports Intel® Optane™ DCPMM††
3. 4 PCI-E 3.0 x16, 2 PCI-E 3.0 x8 slots
4. 8 Hot-swap 3.5" SATA3 drive bays; RAID 0, 1, 5, 10
5. Optional DVD-ROM drive, optional support: 2 fixed 2.5" NVMe/SSD/HDD, 1 M.2 support
6. 2x 10GBase-T LAN ports with Intel X722
7. 1000W Redundant Power Supplies Titanium Level (96% efficiency)
Thông số kỹ thuật Máy chủ SuperServer SYS-6029P-TRT
| Server | |
| CPU Sockets | 2x Socket |
| CPU Support | Intel Xeon Scalable Processors Gen 1 & 2; 2 x UPI; TDP 70-205W. |
| RAM Support | 16x DIMM slots; Up to 4TB 3DS ECC DDR4-2933MHz |
| Drive Bays | 8x Hot-swap 3.5" |
| M.2 Interface | 1x M.2 Interface: PCI-E 3.0 x4; 2280, 22110 |
| RAID Controller | Intel C621 |
| RAID Support | RAID 0, 1, 5, 10 |
| Form Factor | 2U |
| PCIe | 4 x PCI-E 3.0 x16, 2 x PCI-E 3.0 x8 slots |
| I/O Ports | Rear USB: 2x USB 3.0 + 2 USB 2.0; Front USB: 2x USB 2.0; USB Header: 1x Type A; 1x VGA port; 2x Fast UART 16550 serial; 2x COM Ports (1 rear, 1 header); 2x SuperDOM |
| Network Interface | 2x RJ45 10 Gigabit Ethernet LAN ports; 1x RJ45 Dedicated IPMI LAN port |
| Power Supply | 1000W |
| Redundant Power | YES |
| NVMe | 2x 2.5" NVMe with optional NVMe Drive kit |
| System Fan | 3 Heavy duty 80mm fans with PWM fan speed control |
Cấu hình tùy chọn
Product
Máy chủ SuperServer SYS-6029P-TRT
44,881,440đ
CPU
x
Intel Xeon Silver 4110 Processor (8C/16T 11M Cache, 2.10 GHz) - CD8067303561400
10,584,000đ
x
Intel Xeon Silver 4210 Processor (10C/20T 13.75M Cache, 2.20 GHz) - CD8069503956302
10,160,640đ
x
Intel Xeon Gold 6226 Processor (12C/24T 19.25M Cache, 2.70 GHz) - CD8069504283404
51,885,240đ
x
Intel Xeon Platinum 8253 Processor (16C/32T 22M Cache, 2.20 GHz) - CD8069504194601
92,658,720đ
x
Intel Xeon Gold 5215 Processor (10C/20T 13.75M Cache, 2.50 GHz) - CD8069504214002
36,340,920đ
x
Intel Xeon Platinum 8256 Processor (4C/8T 16.5M Cache, 3.80 GHz) - CD8069504194701
204,656,760đ
x
Intel Xeon Gold 5218 Processor (16C/32T 22M Cache, 2.30 GHz) - CD8069504193301
37,221,360đ
x
Intel Xeon Silver 4214 Processor (12C/24T 16.5M Cache, 2.20 GHz) - CD8069504212601
14,958,720đ
x
Intel Xeon Gold 6238 Processor (22C/44T 30.25M Cache, 2.10 GHz) - CD8069504283104
76,325,040đ
x
Intel Xeon Gold 5220 Processor (18C/36T 24.75M Cache, 2.20 GHz) - CD8069504214601
45,418,560đ
x
Intel Xeon Silver 4216 Processor (16C/32T 22M Cache, 2.10 GHz) - CD8069504213901
19,756,800đ
x
Intel Xeon Gold 6252 Processor (24C/48T 35.75M Cache, 2.10 GHz) - CD8069504194401
106,745,760đ
x
Intel Xeon Platinum 8260 Processor (24C/48T 35.75M Cache, 2.40 GHz) - CD8069504201101
139,898,880đ
x
Intel Xeon Gold 6254 Processor (18C/36T 24.75M Cache, 3.10 GHz) - CD8069504194501
107,960,160đ
x
Intel Xeon Platinum 8268 Processor (24C/48T 35.75M Cache, 2.90 GHz) - CD8069504195101
180,642,000đ
x
Intel Xeon Gold 5222 Processor (4C/8T 16.5M Cache, 3.80 GHz) - CD8069504193501
36,340,920đ
x
Intel Xeon Silver 4215R Processor (8C/16T 11M Cache, 3.20 GHz) - CD8069504449200
23,377,200đ
x
Intel Xeon Platinum 8270 Processor (26C/52T 35.75M Cache, 2.70 GHz) - CD8069504195201
216,284,640đ
x
Intel Xeon Gold 5220R Processor (24C/48T 35.75M Cache, 2.20 GHz) - CD8069504451301
45,418,560đ
x
Intel Xeon Silver 4210T Processor (10C/20T 13.75M Cache, 2.30 GHz) - CD8069504444900
16,242,600đ
x
Intel Xeon Gold 6256 Processor (12C/24T 33M Cache, 3.60 GHz) - CD8069504425301
115,003,680đ
x
Intel Xeon Silver 4214Y Processor (12C/24T 16.50M Cache, 2.20 GHz) - CD8069504294401
22,830,720đ
x
Intel Xeon Gold 6226R Processor (16C/32T 22M Cache, 2.90 GHz) - CD8069504449000
37,980,360đ
x
Intel Xeon Platinum 8276 Processor (28C/56T 38.5M Cache, 2.20 GHz) - CD8069504195501
254,659,680đ
x
Intel Xeon Gold 6238R Processor (28C/56T 38.5M Cache, 2.20 GHz) - CD8069504448701
76,325,040đ
x
Intel Xeon Silver 4210T Processor (10C/20T 13.75M Cache, 2.30 GHz) - CD8069504444900
16,242,600đ
x
Intel Xeon Silver 4209T Processor (8C/16T 11M Cache, 2.20 GHz) - CD8069503956900
14,633,520đ
x
Intel Xeon Gold 6242R Processor (20C/40T 35.75M Cache, 3.10 GHz) -CD8069504449601
73,896,240đ
x
Intel Xeon Silver 4210R Processor (10C/20T 13.75M Cache, 2.40 GHz) - CD8069504344500
10,929,360đ
x
Intel Xeon Gold 6246R Processor (16C/32T 35.75M Cache, 3.40 GHz) - CD8069504449801
97,759,200đ
x
Intel Xeon Gold 6248R Processor (24C/48T 35.75M Cache, 3.00 GHz) - CD8069504449401
78,875,280đ
x
Intel Xeon Silver 4210T Processor (10C/20T 13.75M Cache, 2.30 GHz) - CD8069504444900
16,242,600đ
x
Intel Xeon Silver 4214Y Processor (12C/24T 16.50M Cache, 2.20 GHz) - CD8069504294401
22,830,720đ
x
Intel Xeon Gold 6258R Processor (28C/56T 38.5M Cache, 2.70 GHz) - CD8069504449301
115,368,000đ
x
Intel Xeon Silver 4214R Processor (12C/24T 16.50M Cache, 2.40 GHz) - CD8069504343701
16,106,400đ
RAM
x
Ram Samsung 16GB DDR4-2666 RDIMM
3,960,000đ
x
Ram Samsung 64GB DDR4-2400 LRDIMM
0đ
x
Ram SamSung 64GB DDR4-2666 LRDIMM
9,504,000đ
x
Ram Samsung 16GB DDR4-2400 RDIMM
3,960,000đ
x
Ram Samsung 16GB DDR4-2666 RDIMM
3,960,000đ
x
Ram Samsung 32GB DDR4-2400 RDIMM
5,064,000đ
x
Ram Samsung 32GB DDR4-2666 RDIMM
4,608,000đ
HDD
x
SSD Samsung PM883 240G SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH240HAHQ
2,798,400đ
x
HDD WD ULTRASTAR DC HA210 2TB 3.5" 128MB Cache, 7200RPM, SATA
2,904,000đ
x
SSD Samsung PM883 480G SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH480HAHQ
3,432,000đ
x
HDD WDC ULTRASTAR DC HC310 4TB 3.5, 256MB Cache, 7200RPM, SATA
4,699,200đ
x
SSD Samsung PM883 960G SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH960HAJR
5,016,000đ
x
SSD Samsung PM883 1.9T SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH1T9HMLT
9,134,400đ
x
SSD Samsung PM883 3.8T SATA 6Gb/s V4 TLC VNAND 2.5" 7mm (1.3 DWPD) - MZ7LH3T8HMLT
18,638,400đ
x
SSD Intel S4510 Series 480GB, 2.5in SATA 6Gb/s, 3D2, TLC (SSDSC2KB480G8)
3,748,800đ
x
SSD Intel S4510 Series 960GB, 2.5in SATA 6Gb/s, 3D2, TLC (SSDSC2KB960G8)
5,966,400đ
x
SSD Intel S4510 Series 1.92TB, 2.5in SATA 6Gb/s, 3D2, TLC (SSDSC2KB019T8)
9,768,000đ
RAID
Card Raid Supermicro AOC-S2208L-H8iR & 2x CBL-SAST-0507-01
14,208,000đ
Card Raid Supermicro AOC-S3008L-L8e & 2x CBL-SAST-0593
5,400,000đ
Card Raid LSI MegaRAID SAS 9361-8i
9,815,520đ
Card Raid Supermicro AOC-S2308L-L8i & 2x CBL-SAST-0507-01
4,776,000đ
Card Raid Supermicro AOC-S3008L-L8i & 2x CBL-SAST-0593
5,496,000đ
Card Raid LSI MegaRAID SAS 9271-8i
7,752,000đ
Card Raid Supermicro AOC-S2308L-L8e & 2x CBL-SAST-0507-01
4,632,000đ
Card Raid Supermicro AOC-S3108L-H8IR-16DD & 2x CBL-SAST-0593
7,395,840đ
Card Raid LSI MegaRAID SAS 9261-8i
3,744,000đ
Network Card
Network card Supermicro AOC-STG-I2 (2x CX4, 10GbE)
6,960,000đ
Network card Supermicro AOC-STGN-i1S (1x SFP+, 10GbE)
3,480,000đ
Network card Supermicro AOC-SG-I2
0đ
Network card Supermicro AOC-STG-i2T (2x RJ45, 10GbE)
8,880,000đ
Network card Supermicro AOC-SGP-i2 (2x RJ45, GbE)
2,616,000đ
Network card Supermicro AOC-STG-B4S (4x SFP+, 10GbE)
10,440,000đ
Network card Supermicro AOC-STGN-i2S (2x SFP+, 10GbE)
8,040,000đ
Network card Supermicro AOC-SGP-i4 (4x RJ45, GbE)
4,800,000đ
Network card Supermicro AOC-SG-I4
0đ
Tray
Supermicro Converter Drive Tray 3.5" to 2.5" (MCP-220-00043-0N)
456,000đ
